Brand Name: TIANYANG
Type: Centrifugal Spray Granulation Dryer
Model: LX Series
Material: SUS304, SUS316L
Max. Water Evaporation Capacity: 5-1000kg/h
Heating Method: Electricity+steam, fuel oil, gas, up to the user.
Applications: Ceramics, magnetic materials, new energy materials, new metal materials, inorganic medicines, biology, food, chemicals, etc.
Warranty: 1 year
Product Description
LX-Series fully automatic energy-saving centrifugal spray granulation dryer (hot air drying) is mainly for the slurry with high solid content to be sprayed and granulated by a high-speed centrifugal atomizer. Filling the film, the residual moisture content and loose specific gravity are stable, and it is suitable for isostatic pressing and molding products. The service life of the mold is relatively longer than that of manual and mechanical granulation. The pressed product has better consistency and higher finish.
Main Features
* Fast drying speed and high efficiency;
* It can handle high concentration and high viscosity liquid;
* Products with less fine powder content and good dispersibility, fluidity and solubility can be obtained;
* The product has good sphericity and excellent particle size distribution, and the particle size of the product can be adjusted arbitrarily;
* The production process is simplified, automatic control, convenient operation, suitable for continuous production control.
Scope of Application
LX-series automatic energy-saving centrifugal spray granulation drying equipment has been used in electronic ceramics, precision ceramics, ceramics, magnetic materials, new energy materials, new metal materials, inorganic medicines, biology, food, chemicals, fine chemicals and other industries.
Technical Parameter
Model |
LX Centrifugal Spray Granulation Drying Machine |
|||||||||||||||||
Max. Water Evaporation Capacity (kg/h) |
5 |
10 |
15 |
20 |
25 |
30 |
50 |
100 |
120 |
150 |
200 |
300 |
400 |
500 |
600 |
800 |
1000 |
|
Inlet Temperature (℃) |
230-350℃ |
|||||||||||||||||
Out Temperature (℃) |
90-150℃ |
|||||||||||||||||
Spray Type |
High Speed Centrifugal Atomizer |
|||||||||||||||||
Atomization Rotated Speed (RPM) |
0-18000 |
|||||||||||||||||
Spray Disc Diameter (mm) |
55-65 |
70-80 |
80-120 |
120-150 |
150-180 |
|||||||||||||
Heating Sources (Option) |
Oil, natural gas, coal gas, liquefied gas, marsh gas, coalmine, steam, electricity, etc. |
|||||||||||||||||
Remarks: Water evaporation capacity depends material property, solid content, inlet & outlet temperature.
